XL 100

Small R&D Rotary Tablet Press

Contents

Smallest R&D Rotary Tablet Press

The smallest R&D rotary tablet press that offers all the features of larger tablet presses for single-layer applications. The XL 100 Tablet Press is a portable, robust, small scale rotary press and widely considered to be the standard for product development.

The exchangeable turret permits the use of any size of standard press tools, including EU, TSM, B, D, and BB. The mixed turret design enables scientists to develop B and D size tablet formats on the same turret.

The XL 100 may be fully instrumented to permit comprehensive data collection analysis with the KORSCH R&D software. An optional production control module permits the manufacture of clinical batches with press force control, single-tablet rejection, and full array of electronic audit trails.

Single-Layer and Multi-Layer Capability	Single-Layer
Punch Stations	13 / 12 / 10 / 8
Compression Force	10/60 kN
Tablet Diameter max.	25 mm
Containment Capability	DryCon® und WipCon®
Tablet Output max.	up to 93,000 tablets/h

Compact, flexible & ergonomic design

Easy handling and cleaning
Wide range of accessories
Configurations for small material quantities
Portable

A machine for every application

From product characterization and formulation development to scale-up and troubleshooting
Trials and troubleshooting, up to scale-up
Single-Layer Tablets
Multi-Layer Tablets
Tab-in-Tab

Data acquisition & analysis software

Advanced instrumentation
Collects values and measurements to understand the behavior of a product under compression
Connection to external tablet testing equipment to automatically collect and process the corresponding data in correlation with the compression force data

Supported by Science

KORSCH and MEDELPHARM scientists have been collaborating with customers on tableting projects for decades.
Our mission and passion is problem solving and helping accelerate your product development
